1026 Dom Tube Precision Seamless Tube Honed Cylinder Tube
Outer Dimensions:4.0mm – 60.0mm;
Standard:ASTM, ASME, JIS, AISI, AMS, EN, SAE, DIN, NF, TOCT, DS, DTD, GB;
Size: 5.0 – 1219.2 mm;
Schedules: SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS;
Type: Seamless / ERW/ EFW / Welded / Fabricated / CDW / DOM / CEW;
Buy 1026 Tube&Pipe at best price.
Best service with 24 hour`s reply;
Email: sale@puwosmls.com
Besides containing carbon as their specific element, carbon steel grade AISI 1026 contains a significant content of both silicon and manganese. To be exact, the NOM B-203 Grade 1026 mechanical pipes contains about 0.4% silicon and 1.2% manganese. There are several specifications covered by carbon steel grade SAE 1026 Tubing including ASTM A29, ASTM A510, ASTM A512 as well as ASTM A513.
1026 Steel Equivalent:
| Grade | UNS | EN |
| AISI 1026 / SAE 1026 | G10260 | 1.9415 |
1026 Steel Tubing Properties - Chemical Composition:
| Grade | C | Mn | P≤ | S≤ |
| 1026 | 0.22-0.28 | 0.60-0.90 | 0.040 | 0.050 |
1026 Tubing Mechanical Properties:
| Properties | Metric | Imperial |
| Tensile strength | 490 MPa | 71100 psi |
| Yield strength | 415 MPa | 60200 psi |
| Bulk modulus (typical for steel) | 140 GPa | 20300 ksi |
| Shear modulus (typical for steel) | 80.0 GPa | 11600 ksi |
| Elastic modulus | 190-210 GPa | 27557-30458 ksi |
| Poisson’s ratio | 0.27-0.30 | 0.27-0.30 |
| Elongation at break (In 50 mm) | 15.00% | 15.00% |
| Reduction of area | 40.00% | 40.00% |
| Hardness, Brinell | 143 | 143 |
| Hardness, Knoop (converted from Brinell hardness) | 163 | 163 |
| Hardness, Rockwell B (converted from Brinell hardness) | 78 | 78 |
| Hardness, Vickers (converted from Brinell hardness) | 149 | 149 |
Puwo is not only a distributor, but also a manufacturer. Puwo has its own steel pipe processing and manufacturing factory. Therefore, if you buy steel pipes directly from Puwo, the price will be lower than the dealer's price. Whether the customer needs 1 ton, 1,000 tons, or a few steel pipes, Puwo's employees will serve customers conscientiously and provide customers with high-quality and low-cost steel pipes.
♣ For more A1026 steel pipe prices, please contact us for discounted prices. Steel pipe samples are free. ( Email: sale@puwosmls.com)
Available Steel Grade:
| SAE/AISI: | SAE1020, SAE1026, SAE1045, SAE4130, SAE4140 |
| DIN: | ST52, ST52.3, ST52.4 |
| EN: | E355, C45E, 25CrMo4, 42CrMo4, CK45, S45C, E410, E470 |
| GB: | 20#, 45#, 16Mn, Q345B, Q345C, Q345D, Q345E, 25Mn, 27SiMn, |
